Centrifugal Pumps – HP Models

A multi-stage pump with a ring-section design intended for liquids that are clean, neutral, polluted, or aggressive. Features include an axial or radial pump inlet with 90-degree increment positioning for flanges, a radial discharge flange with 90-degree increment positioning, rings that are replaceable, customized dimensions, fitting key fixed impellers, connective shaft ends (one or two), and mechanical seal or stuffing box shaft sealing options.

A multi-stage pump with a ring-section design that can manage polluted, neutral, aggressive or clean materials. Features include shaft seal or jacket cooling options, flexible dimensions, mechanical seal or stuffing box shaft sealing, simplified part replacement, balance disk or drum axial thrust, bearings that are sleeve or anti-friction with lubrication as an option, intermediate discharge flange, and wear rings made from composite material.

A multi-stage pump with a ring-section design intended for materials that are aggressive, neutral, contaminated or carry solids of up to 15%. Features include 90-degree increment positioning for flanges, mechanical seal or stuffing box shaft sealing options, impellers that are individually balanced to deliver axial thrust compensation, 4-pole speed, a cost-effective build, oil or grease options for lubrication, and a closed fixed (with fitting key) impeller.

A multi-stage pump with a ring section design that is built for contaminated, aggressive, or neutral materials and with solids of up to 15%. Features include 90-degree increment positioning for flanges, lubrication from oil or grease, 4-pole speed, stuffing box or mechanical seal shaft sealing, optical and digital indicator options for device-managed axial thrust compensation, a closed and fixed (through fitting key) impeller, and customized dimensions, inlet suction casing, discharge flanges, and drive options.
